Resistive Pressure Transducer

The Resistive Pressure Transducer is a high-precision pressure sensing device based on resistive strain technology. It is mainly used for pressure monitoring and control of power switchgear, pneumatic mechanisms, and sealed air chambers, ensuring the reliable operation of power equipment. This product adopts high-precision resistive strain elements, with accurate pressure measurement and fast response speed. It can monitor the internal pressure change of equipment in real time, and provide reliable pressure data for equipment status monitoring and fault warning. As a pressure sensor supporting power equipment, the Resistive Pressure Transducer has good medium compatibility and environmental adaptability, can adapt to different pressure media and working environments, and is an important part of power equipment status sensing.

In terms of technical performance and scenario adaptability, this resistive pressure transducer adopts a diffused silicon resistive strain core, with high measurement accuracy, good repeatability, and low hysteresis, and can perform long-term stable measurement without drift. The equipment adopts a fully sealed structure design, with good waterproof, dustproof and anti-vibration performance, high protection grade, and can work reliably in harsh environments such as industrial sites and outdoors. In response to the application scenarios of power switchgear, we have optimized the pressure range, interface specifications and output signals of the product, which can directly support the operating mechanisms and sealing systems of our circuit breakers and reclosers. We can also customize the pressure range, connection method and output type according to customers' equipment parameters to meet the pressure monitoring needs of different power equipment.

Application Fields



• Pressure monitoring of circuit breaker operating mechanisms
• Pressure detection of sealed air chambers of switchgear
• Pneumatic and hydraulic system pressure control
• Power equipment status monitoring
• Industrial automation pressure measurement

We can provide full-range customization services for this pressure transducer. We can customize parameters such as pressure range, connection interface, output signal, and power supply mode according to customer needs, and also customize special versions such as anti-corrosion type, explosion-proof type, and high temperature type according to special working conditions. Our professional technical team will conduct a comprehensive feasibility assessment of the customization plan, provide professional selection suggestions, and follow up the whole process from design, prototyping to testing to ensure that the customized products fully adapt to customers' equipment and application scenarios and meet differentiated pressure monitoring needs.

We have established strict quality inspection standards for sensor products, and implement full-process quality control for this pressure transducer. Core strain cores have all undergone strict incoming inspection and temperature drift tests to ensure stable performance. Each process in the production process is set with exclusive quality inspection nodes. Before delivery, finished products must pass full inspections such as accuracy calibration, temperature cycle test, sealing test, and aging test. A 100% full inspection system is implemented, and each product is accompanied by a calibration certificate. We support third-party metrological institutions for calibration and inspection to ensure that each delivered transducer has up-to-standard accuracy and reliable performance.

We provide a one-year whole-machine warranty and lifetime technical support for this product. The after-sales technical team can respond to customers' technical consultation and problem feedback within 24 hours, and provide technical services such as selection guidance, installation and commissioning guidance, and fault troubleshooting. For customers using in batches, we can provide regular calibration and maintenance services to ensure long-term stable operation of the transducers. At the same time, we regularly conduct customer return visits, collect use experience and demand suggestions, continuously optimize product performance, and provide customers with long-term reliable pressure monitoring solutions.
